5m 10m Double Side Thermal Conductive Tape 8-30mm Width Blue Heat Transfer Tape Adhesive Cooling Heatsink for Computer CPU GPU

5m 10m Double Side Thermal Conductive Tape 8-30mm Width Blue Heat Transfer Tape Adhesive Cooling Heatsink for Computer CPU GPU

Product Features
● High tacky thermal conductive PSA. Only pressure is needed to form an excellent bond and thermal interface
● The performance of thermal conductivity, insulation, buffer and high tacky make it as the best choice for electronic application.
● Flexible and conformable. Ideal for uneven surfaces.
● Stable and economical with different thicknesses and constructions.

Product Parameters
Tape carrier: Glass Fabric
Adhesive: Thermally Conductive PSA
Release Liner: Blue PE Film
Length: 5m/10m
Width: 8mm/10mm/12mm/15mm/20mm/25mm/30mm
Thickness: 0.15mm/0.30mm
Thermal conductivity: 1.2W/m-k
Adhesion: 12N/25mm
Withstand voltage: 3.5KV/mm
Temperature resistance (short term): 120°C/248°F
Temperature resistance (long term): 80°C/176°F

Application
● Assembly of LED light bar module and metal frame bezel.
● Assembly of DDR-RAM module and heat sink.
● Electronic components: IC, COP, CPU, MOS, etc.
● M/B, PS, PCB, LCD, PDP , PC, etc.

Notes
● Please keep the glue surface clean and dry.
● After peeling off the thermally conductive double-sided adhesive release paper, press the double-sided thermally conductive adhesive evenly with your fingers (with a little force).
● Tape takes 72 hours to reach maximum bond strength.
● Try to avoid touching the tape with your hands. You can press harder to increase the adhesion between the tape and the object.
● In the case of low temperature in winter, when using thermal conductive tape, it is a small trick to heat to increase the viscosity of thermal conductive double-sided tape.

Package Include
1x Thermally Conductive Adhesive Tape
