ASUS PRIME A320M-F Motherboard AM4 AMD A320 Chipset DDR4 32GB Micro ATX Used
Description
- High-concerned chemical: None
- RAID Supported: Yes
- Processor compatibility: AMD Ryzen 4000 Series-R3,AMD Ryzen 5000 Series-R5,AMD Ryzen 3000 Series-R9
- Usage Scenario: Gaming,Office
- Back I/O Ports: 1x RJ45,VGA (D-Sub),6 x USB 2.0,3 x Audio Jacks,PS/2
- Onboard LAN: 1x RJ45
- Number of SATA Ports: 4
- Storage Interface Type: SATA 3
- Number of PCI: 0
- Number of PCIe x 1: 2
- Number of PCIe x 4: 0
- Number of PCIe x 16: 1
- PCI – E standards: PCI-E 3.0
- Number Of Memory Slots: 2
- Support Memory Type: DDR4
- Memory channel: Double
- Form Factor: CeB
- Package: No
- Maximum Ram Capacity: 32 GB
- Form Factor: Micro-ATX
- Chipset Manufacturer: AMD
- Battery Included: No
- With CPU: No
- Chipset: AMD A320
- Application: Desktop
- Socket Type: AM4
- Brand Name: Asus
- Special Features: None
- Origin: Mainland China
Supports Ryzen 3000 4000G 5000 Series
AM4 slot, supports 3rd/2nd/1st generation AMD Ryzen â„¢ / 2nd and 1st generation AMD Ryzen â„¢ Equipped with Radeon â„¢ Vega Graphics / Athlon â„¢ Equipped with Radeon â„¢ Vega Graphics / 7th generation A-series/Athlon X4 processor
High performance Ryzen ™ The processor is based on the innovative Zen core architecture, supporting up to 8 cores and equipped with Radeon ™ Vega Integrated graphics card. Equipped with dual channel DDR4 memory, native 5Gbps USB 3.1 Gen 1, and 16 PCI Express ® 3.0/2.0 channels, these AMD AM4 socket processors provide excellent computing performance.
AMD A320 chipset
AMD A320 chip supports AMD ® AM4-socket Ryzen ™ Processor, 7th generation A-series APU and Athlon ™ CPU。 In addition, it provides 2 USB 3.0 interfaces and 4 6Gbps SATA interfaces for faster and more convenient data transfer.
Motherboard chip
Integrated chip graphics card/sound card/network card
Main chipset AMD A320
The chipset description adopts AMD A320 chipset
Display chip integrated with AMD Radeon R series display chips
Audio chip integrated with Realtek ALC887 8-channel sound effect chip
Network card chip onboard Realtek RTL8111H gigabit network card
Processor specifications
CPU type AMD Ryzen/7th generation A-series/Athlon II/Athlon
CPU socket socket AM4
CPU description supports AMD RYZEN processors
Memory specifications
Memory type 2 × DDR4 DIMM
Maximum memory capacity 32GB
Memory Description: Supports dual channel DDR4 2400/2133 MHz memory
Storage Expansion
PCI-E Standard PCI-E 3.0
PCI-E X16 slot 1
2 PCI-E X1 slots
Storage interface 4 x SATA III interface
I/O interface
USB interface 6 x USB 3.1 Gen1 interface (2 built-in+4 backplane), 6 x USB 2.0 interface (4 built-in+2 backplane)
Video interface 1 x VGA interface
One 4-pin power interface and one 24 pin power interface
Other interfaces: 1 x RJ45 network interface, 3 x audio interface, 1 x PS/2 mouse interface, 1 x PS/2 keyboard interface
Plate type
Motherboard type Micro ATX board type
Dimensions 21.6 × 19.3cm
