GSM 3G 4G 5G Antenna Outdoor Omni Aerial High Gain 15dBi RP SMA Male TS9 CRC9 Waterproof Magnetic Antenna for Wifi Router Modem
Description
- High-concerned chemical: None
- Connector Type: Soldering
- Cable Length: 300cm
- Pins: Yellow
- Specification: 3M
- Gain(dB): 15dBi
- Model Number: 5G antenna
- Brand Name: NOWEPOCH
- Origin: Mainland China
- Certification: CE,FCC,RoHS
- Antenna Frequency: 600-6000Mhz
- Antenna Connector: SMA Male / RP SMA Male / TS9 /CRC9
- Antenna Height: 16cm
- Antenna Magnetic Base: 3.5cm
Specifications:
* Product name: GSM / GPRS / 3G / 4G / 5G waterproof sucker antenna
* Antenna gain: 15dBi
* Antenna frequency band: 600-6000mHz
* Antenna height: 16cm
* Antenna interface: SMA Male / RP SMA Male / TS9 / CRC9* Cable Length ：3 Meters
* Caable material: RG174
* Max Power: 50W
* Impedance: 50 Ω
* VSWR: ≤ 1.5
* Polarization mode: vertical polarization
* Scope of application: Mobile / Unicom / telecom / whole network module / smart home and other transmission equipment
Features:
* Compatible with Mobile, Unicom and Telecom.
* 15dBi full Band frequency high gain waterproof antenna.
* Support WCDMA.LET , DTU, 5G, 4G, 3G, GSM, GPRS, etc.
Additional information
| High-concerned chemical | None |
|---|---|
| Connector Type | Soldering |
| Cable Length | 300cm |
| Pins | Yellow |
| Specification | 3M |
| Gain(dB) | 15dBi |
| Model Number | 5G antenna |
| Brand Name | NOWEPOCH |
| Origin | Mainland China |
| Certification | CE,FCC,RoHS |
| Antenna Frequency | 600-6000Mhz |
| Antenna Connector | SMA Male / RP SMA Male / TS9 /CRC9 |
| Antenna Height | 16cm |
| Antenna Magnetic Base | 3.5cm |
| Color | CRC9, RP SMA Male, SMA Male, TS9 |
Reviews
Vendor Information
Related Products
Z***h (verified owner) –
A very nice antenna that is inexpensive and fulfills its purpose well enough to pick up the signal. So, I am definitely satisfied because in my case, when connected to the modem, the signal strength doubled, allowing me to send and receive twice as much in the same time, and it’s great because it can be placed through a window, and the magnetic base sticks very well to the metal window sill, so everything is great.
L***y (verified owner) –
Shows improvement in both download and upload speed as well as range. Can’t expect much more for the price!
o***y (verified owner) –
It was a surprise how well it worked. I have very poor signal this makes it work.
V***o (verified owner) –
Good quality, signal also adequate, tested on 3372s huawei modem
E***j (verified owner) –
The antena are really 5g, find good spot for the router i was first floor, the speed with a 5g router was 60 with 5 , not so good with this i got allmost 100 and 20 mb so is good , and than depends allways from provider. There were i am is like a bunker and i am far away from tower imaging 2 ore 3 floor and like 5 km from the tower. I did the test 3 times and the speed was like 300 with 50 mb, and 400 with 50. Even for normal router good coverage of the place even in blind spot .
T***o (verified owner) –
Excellent, we managed to solve the cell signal problem at my father’s house. I recommend it!
A***r (verified owner) –
Noticed a good difference, minimum 100 mb for 5g.
AliExpress Shopper (verified owner) –
I don’t know what the gain ratio might be, but I used it as an external antenna for an internet amplifier: It works, respect to the seller! And may the rod that came to our Earth be cursed!!! Peaceful skies to everyone!!!
