Jsdsolar 4KW 24V Hybrid Solar Pure Sine Wave Inverter MPPT 100A Solar Charger PV 500VDC Off Grid Built-in Wifi Support LiFePo4
Description
- Size: 434.5*284*103mm
- Output Type: SINGLE
- Weight: 6.2kg
- Brand Name: jsdsolar
- Output Frequency: 50/60Hz
- Is Smart Device: Yes
- Origin: Mainland China
- Certification: CE,RoHS,UL
- Rated power: 4000W
- Rated Input Voltage (VAC): 208/220/230/240:L + N + PE
- Voltage Range (VAC): 90 ~ 280 + 3(normalmode);170 ~ 280 + 3(UPS mode)
- Frequency(Hz): 50/60(Auto Adaptive)
- Power Factor(PF): 1
- Wave Form: Pure Sine Wave
- Overload Capacity: 60s @ 102% ~ 110% load; 10s @ 110% ~ 130% load;3s @ 130% ~ 150% load; 0.2s @>150% load
- Max.Efficiency: 92% 24VDC
- Solar Charger Type: MPPT
- Max PV Input Current/Input Power: 18A/5000W
- MPPT Range @ Operating Voltage (VDC): 40-450
- Max PV Open Circuit Voltage(DC): 500
- Max PV Charge Current (A): 100
- Max AC Charge Current (A): 100
- Max. Charge Current (PV + AC)(A): 100
- Battery Rated Voltage (VDC): 24
- Battery Floating Charge Voltage (VDC): 27
- Battery Overcharge Protection (VDC): 30.5
- Interface: RS232/RS485 /USB/Dry Contact
- Storage Temperature: -15 ℃ ~ 60 ℃
- Monitoring: WiFi (Built-in)
New jsdsolar 4KW 24V Hybrid Solar Silent Inverters 230VAC Off Grid Pure Sine Wave Built-in Wifi Monitor MPPT 100A PV 5000W For Home CAN RS485 Free Tax
4KW inverter upgrade functions and features
★Pure sine wave inverter
★Configurable dual AC output
★Charging current up to 100A
★Compatible with various batteries types
★Communicate with lithium battery BMS
★With lithium battery BMS activation function
★Over temperature / Over load / Over voltage / Short circuit protection
★Advanced MPPT technology with an efficiency of 99.9%
★Easy to install and operate
Package List:
4KW Inverter * 1, Manual * 1
About Warranty:
2 Year Quality Warranty
|
Models |
J4000E |
|
Rated input voltage |
220/230VAC |
|
Input voltage range |
90-280VAC |
|
Frequency |
50Hz/ 60Hz |
|
Bypass Overload Current |
20A |
|
INVERTER OUTPUT
|
|
|
Rated output power (W)
|
4000W
|
|
Rated output voltage (VAC)
|
230VAC
|
|
Output Topology
|
L + N + PE
|
|
Switch Time
|
10 (APP/UPS mode)/20 (GEN mode)
|
|
Waveform
|
Pure sine wave
|
|
BATTERS
|
|
|
Battery Type |
Lithium / Lead -acid |
|
Rated Battery Voltage |
24Vdc |
|
Max PV charge current |
100A |
|
Max Mains/Generator Charging Current |
100A |
|
Max Hybrid Charging Current |
100A |
|
PV INPUT
|
|
|
PV Charging method
|
MPPT
|
|
PV Maximum Input Power
|
5000W
|
|
PV Maximum Input Current
|
18A
|
|
Max PV Voltage
|
500Vdc
|
|
MPPT Voltage Range
|
40-450Vdc
|
|
MPPT Tracking Efficiency
|
99%
|
|
Max. Battery Inverter Efficiency
|
92%
|
|
COMMUNICATION and GENERAL
|
|
|
Embedded Interfaces |
RS485 / CAN / USB / Dry contact |
|
External Modules (Optional) |
Wifi(Built-in) |
|
Operating Temperature Range |
-10 ~ 60 ℃ |
|
Storage Temperature |
-15 ~ 60 ℃ |
|
Humidity range |
5% is 95% (Conformal protecting) |
|
Cooling Method |
Intelligent Fan |
|
Size (L * W * D) |
434.5*284*103mm |
|
Protection Degree |
IP21 |
|
Net Weight |
6.2kg |
Additional information
| Color | 4KW with Wifi |
|---|---|
| Size | 434.5*284*103mm |
| Output Type | SINGLE |
| Weight | 6.2kg |
| Brand Name | jsdsolar |
| Output Frequency | 50/60Hz |
| Is Smart Device | Yes |
| Origin | Mainland China |
| Certification | CE,RoHS,UL |
| Rated power | 4000W |
| Rated Input Voltage (VAC) | 208/220/230/240:L + N + PE |
| Voltage Range (VAC) | 90 ~ 280 + 3(normalmode);170 ~ 280 + 3(UPS mode) |
| Frequency(Hz) | 50/60(Auto Adaptive) |
| Power Factor(PF) | 1 |
| Wave Form | Pure Sine Wave |
| Overload Capacity | 60s @ 102% ~ 110% load; 10s @ 110% ~ 130% load;3s @ 130% ~ 150% load; 0.2s @>150% load |
| Max.Efficiency | 92% 24VDC |
| Solar Charger Type | MPPT |
| Max PV Input Current/Input Power | 18A/5000W |
| MPPT Range @ Operating Voltage (VDC) | 40-450 |
| Max PV Open Circuit Voltage(DC) | 500 |
| Max PV Charge Current (A) | 100 |
| Max AC Charge Current (A) | 100 |
| Max. Charge Current (PV + AC)(A) | 100 |
| Battery Rated Voltage (VDC) | 24 |
| Battery Floating Charge Voltage (VDC) | 27 |
| Battery Overcharge Protection (VDC) | 30.5 |
| Interface | RS232/RS485 /USB/Dry Contact |
| Storage Temperature | -15 ℃ ~ 60 ℃ |
| Monitoring | WiFi (Built-in) |
| Input Voltage | 24V |
| Output Voltage | 220-240V |
| Ships From | Poland |
