Outdoor Waterproof Wireless Animal Immune Infrared Detector 433MHz Long Working Distance For Home Burglar Wifi /GSM alarm system
Description
- Model Number: FD102
- Brand Name: FD
- Origin: Mainland China
- Certification: CE
- Wireless frequency: 433mhz
- Chip: 1527
- Installation height: 2.2-2.7m
- Detection distance: 12m@25℃
- Detection angle: 110°
- Pet immunity: 25KG
- Working temperature: -20℃-50℃
- Standby current: less than 9 uA
Product description
Outdoor PIR Sensor adopts importer super low power consumption digital microprocessor, random dynamic time division and energy accumulation logic processing technology, patented precision columnar Fresnel lens, Using high intelligent volume recognition + outdoor filter + dual infrared + processor technology, adjustable pulse counting. Working with advanced patented software technology, it features super detection performance and judges the real invader truly and can overcome the shortcoming of false alarm, failed alarm and not alarm.
Please note that this product don’t include the battery.
Feature
Fresnel optical lens + Volume identification can prevent mistaken alarm and omitted alarm
Detection angle: 110°
Transmission mode: Wireless 433.92mhz (1527)
The design of wall mounted and unique plug type installation
Using high intelligent volume recognition + outdoor filter + dual infrared + processor technologyï¼›
Microprocessor with super low power consumption The use of general 2AA batteries for more than 2 years, easy to buy, no need to change the battery(battery NOT included)ï¼›
Dual temperature compensation technologies
Adoption of detection technology of reflective mirror: overcome the shortcoming of traditional detector that does not alarm for crawling in
The technology of adjustable pulse counting
Dual induction technology
Time division technology with random dynamic
Detection distance: 12m@25℃
Pet immunity: 25KG
Installation height: 2.2-2.7m;
Working temperature: -20℃-50℃
Storage temperature: -20℃-60℃Anti-visible light interference: larger than 6500LUX (indoors)
verall dimension: 120*62*46 (mm); cover：135*35*70m
Specification for outdoor sensor
1. Adopting import low power consumption microprocessor + artificial intelligence.
2. Dual induction technology.
3. Dual temperature compensation technology that works well in high temperature.
4. Bottom detecting window that can avoid missing alarm for someone or something go inside by scrawling from underside.
5. Adjustable pulse count.
6. Adopting import high quality infrared sensor.
7. Random dynamic time division technology.
8. Finel Optics Lens to avoiding missing alarm and wrong alarm.
9. Built-in 1600 million address code.
10. Anti white light intensity up to 6500lux, can make alarm even under influence from white light, it can be the leader in this industry around the world.
11. Detecting angle: 110C degree.
12. Wall installation with unique plug-in installation designed.
This device needs to be used with the 433MHz alarm host
Additional information
| Model Number | FD102 |
|---|---|
| Brand Name | FD |
| Origin | Mainland China |
| Certification | CE |
| Wireless frequency | 433mhz |
| Chip | 1527 |
| Installation height | 2.2-2.7m |
| Detection distance | 12m@25℃ |
| Detection angle | 110° |
| Pet immunity | 25KG |
| Working temperature | -20℃-50℃ |
| Standby current | less than 9 uA |
| Color | 1pcs, 2pcs |
