Tuya Smart Mini IP Camera Module 2MP WiFi 14mm PCB Chipset with 2-Way Audio Covert Security Monitor Smart Life DIY Surveillance
Description
- High-concerned chemical: None
- Zoom type: None
- Zoom: None
- Lens Quantity: Single Lens
- AI Functions: Motion Detection
- Color Night Vision: No
- Operating Temperature: -10°-60°
- App name: Smart Life
- Power Mode: Mains Electricity
- Rechargeable Battery Capability: Other
- Rechargeable Battery: None
- Scene: Indoor
- Movement Range(Tilt): Other
- Movement Range(Pan): Other
- Megapixels: 2 MP
- TF Card: None
- Power Supply: Normal
- Installation: Embedded
- Color: black
- is_customized: Yes
- Audio Output: None
- Minimum Illumination(Lux): 0.1
- Viewing Angle : 85°
- Video Compression Format: H.264
- Dimensions (L x W x D)(mm): 14mm
- Camera Stabilization: None
- Power Supply(V): 5V
- Power Consumption(W): 3w
- Supported Mobile Systems: Android,iOS
- Sensor Brand: SmartSens
- Sensor: CMOS
- Model Number: TUYA
- Supported Operating Systems: Windows XP,Windows Vista
- Lens (mm): 3.6mm
- Connectivity: IP/Network Wired
- High Definition: 1080P(Full-HD)
- Style: Mini Camera
- Brand Name: HQCAM
- Special Features: Vandal-proof
- Power Source: Normal
- Shell Material: Plastic
- Origin: Mainland China
- Certification: CE
- Optical Zoom: None
- Smart home platform: Tuya
- Lens: 1.7MM MTV Lens
- Power: 5V /2A Adapter
- Audio: Built-in Audio
- APP: TUYA smart life
Indoor Wifi Tuya Camera, Baby Monitor, Smart Life Home Security Wireless Mini Camera, IP CCTV, Two Way Audio
Mini indoor Wifi Baby Monitoring Wireless Surveillance Home IP Camera 1080p HD Camcorder CCTV Camera
SPECIFICATIONS
H.264 advantages
1. It is approximate 2 times as effective as H.264.
2. Reduces file size up to 50% with the same quality.
3. Supports resolution up to 1920 × 1080.
4. Reduces video noise and increases dynamic range.
5. Extend far greater video quality experience compared to H.264
Features:
1. H.264 2MP
2. H.264 support dual-stream,AVI;0.1M~8Mpbs variable;1~30f/s variable;
3. Color 0.1Lux; B/W 0.01Lux;
4. Support ONVIF, and mobile monitoring;
5. With TF card slot ,support max 128G TF card.
Camera size description：
Wide-angle lens Camera shooting effect photo：
85° perspective lens display
|
Tuya's Camera Parameters |
|
|
2MP wifi ipcamera |
|
|
System structure |
Embedded RTOS,dual-core 32bit DSP,pure hard compression ,watch dog |
|
Sensor |
2.0MP:1/2.9" CMOS image sensor |
|
ankai DSP |
|
|
Video compression |
H.264,support dual stream,AVI;0.1M~6Mpbs variable;1~30f/s variable |
|
Image output |
2MP:Main stream:1920*1080(20fps), |
|
Audio |
External microphone |
|
Noise reduction |
Support 2D/3D |
|
lens |
1.6mm lens/4mm lens |
|
Storage |
Via PC/Mobile Phone/NVR With HDD |
|
Wide dynamic |
Support digital |
|
Network interface |
Wifi |
|
SD Card |
Yes |
|
Reliability |
Comprehensive lightning protection, in line with national and international standards; 7 * 24 hours 65'C high temperature stable and reliable testing (including mounted machine testing) |
|
Other function |
Internal Mic |
|
ONVIF |
Support |
|
Mobile monitoring |
Support multiple mobile monitoring(iOS,Android) |
|
Power |
Standard DC5V |
|
Need to see close objects, please tell me the distance, we will adjust the focal length and send again. |
|
Support for watching surveillance video on multiple platforms
2MP FHD real-time monitoring, Support Windows, Android, IOS.
Note:
The website for viewing the surveillance video on the PC : https://ipc.ismartlife.me/login
2MP FHD Resolution
With 2MP resolution, KAMTP security camera can provide you clearer image/video for you. Clearer videos and clearer pictures, so that you will not miss every detail and maximize the protection of your family.
Support cloud storage and TF recording, cloud storage is more secure and reliable.
Support Multi User Viewing
The camera support share function,you can share the camera to your other mobile phone if need. and it also supports multi camera add into an app to use together.
Your camera can work with Tuya and Smart life APP
How do you connection camera ?
Motion Detection Video
If there s an object activity within the video recording range of the camera, the phone will receive prompt 'Push alarm' message is sent to the Mobile APP.
Additional information
| Sensor Size | hole lens, Wide-angle lens |
|---|---|
| High-concerned chemical | None |
| Zoom type | None |
| Zoom | None |
| Lens Quantity | Single Lens |
| AI Functions | Motion Detection |
| Color Night Vision | No |
| Operating Temperature | -10°-60° |
| App name | Smart Life |
| Power Mode | Mains Electricity |
| Rechargeable Battery Capability | Other |
| Rechargeable Battery | None |
| Scene | Indoor |
| Movement Range(Tilt) | Other |
| Movement Range(Pan) | Other |
| Megapixels | 2 MP |
| TF Card | None |
| Power Supply | Normal |
| Installation | Embedded |
| Color | black |
| is_customized | Yes |
| Audio Output | None |
| Minimum Illumination(Lux) | 0.1 |
| Viewing Angle | 85° |
| Video Compression Format | H.264 |
| Dimensions (L x W x D)(mm) | 14mm |
| Camera Stabilization | None |
| Power Supply(V) | 5V |
| Power Consumption(W) | 3w |
| Supported Mobile Systems | Android,iOS |
| Sensor Brand | SmartSens |
| Sensor | CMOS |
| Model Number | TUYA |
| Supported Operating Systems | Windows XP,Windows Vista |
| Lens (mm) | 3.6mm |
| Connectivity | IP/Network Wired |
| High Definition | 1080P(Full-HD) |
| Style | Mini Camera |
| Brand Name | HQCAM |
| Special Features | Vandal-proof |
| Power Source | Normal |
| Shell Material | Plastic |
| Origin | Mainland China |
| Certification | CE |
| Optical Zoom | None |
| Smart home platform | Tuya |
| Lens | 1.7MM MTV Lens |
| Power | 5V /2A Adapter |
| Audio | Built-in Audio |
| APP | TUYA smart life |
1 review for Tuya Smart Mini IP Camera Module 2MP WiFi 14mm PCB Chipset with 2-Way Audio Covert Security Monitor Smart Life DIY Surveillance
Vendor Information
Related Products
b***n (verified owner) –
Very fast delivery. Nice.
Adding cam in tuya no problem.
Onvif and rtsp-stream available – for me very important.
Video in fulll hd with very good quality. And substream (i use the nvr frigate, so this is important for recognition). Very nice wide viewing angle.
Audio is working (micro and speaker are ok).
Getting hot, i will add a cooler.
Everything is really ok and better than expected.
AliExpress Shopper (verified owner) –
Excellent camera, shows beautifully, connects quickly to Tuya, the memory card works adequately, and you can mute the speaker by cutting the red wire that goes to it and it will stay silent forever 😁😁😁
b***n (verified owner) –
Already the third camera. Work perfectly and deliver a great image. Audio with speaker and microphone also works fine.
Unbeatable for the price.
f***r (verified owner) –
very discreet. easy to install
AliExpress Shopper (verified owner) –
Very good!! I tested the image, sound (speaker and microphone), Tuya connection, and motion detection. Everything corresponds very well with the characteristics announced by the supplier.
AliExpress Shopper (verified owner) –
Good for the price, good for the price, good for the price.
V***r (verified owner) –
The image quality is average.
but it’s okay, not critical
M***n (verified owner) –
Meets my expectations perfectly. Connection to Tuya was immediate.
