Type-C Expansion Card ASM3142 Controller Dual USB-C Port Docking Station TYPE-C Port Monitor Dock Adapter Cards for Desktop

USB 3.1 10Gbps Gen 2 Expand Card Riser ASM3142 Controller DP 4K Video Adapter Converter Dual USB-C Port Docking Station
Features:
1.Enhanced Performance Chipset: Featuring the ASM3142 chipset, this type-C expansion card unlocks the full potential of USB 3.1 Gen2 Multiple IN-s, ensuring optimal 10Gbps data utilization and delivering a highly integrated, application-specific solution for your PC builds.
2.Versatile 4K Video Output: Simply connect your Mini DisplayPort (Mini-DP) 4K input from your graphics card and instantly access crisp 4K video from the DP 4K video adapter converter with seamless support for DisplayPort, Mini DP, or Thunderbolt 2 video sources to USB-C output.
3.High-Speed Data & Power: Experience true 10Gbps data transfer rates and efficient 5V power supply, meeting USB 3.1/3.0 standards. The USB 3.1 10Gbps gen 2 expand card riser supports USB 3.0, USB 2.0, and USB 1.1 devices for compatibility.
4.Driver-Free Convenience: Enjoy plug-and-play ease with built-in self-powered IC, no extra power required. This dual USB-C port docking station works natively on Windows 10, 11, Mac OS, and Linux; driver only needed for Windows 7.
5.Innovative Full-Function Port: The type-C port monitor dock adapter cards transfer both USB 3.1/3.0 data and power, plus connect USB-C video devices. Its reversible design supports 5V/3A charging and superior connectivity for modern peripherals.

Specification:
Description
1. Chipset: ASM3142 supports the new function of USB 3.1 Gen2 – multiple inputs (Multiple IN-s), which can fully utilize the available bandwidth of the USB 3.1 Gen2 bus, realize full utilization of the 10Gbps data rate, and provide a highly integrated, application-specific design.
2. You need to connect the Mini DisplayPort (Mini-DP) 4K input of the graphics card, and then you can get 4K video from the Type-C output. Compatible with DisplayPort (DP), Mini DP or Thunderbolt 2 video sources to Type-C USB-C output.
3.10Gbps data transmission: Supports 10Gbps data transmission rate and 5V power supply. Complying with USB 3.1/3.0 basic specifications, the output interface is USB 3.0 and Type-C/Type-E. Compatible with USB 3.0 SuperSpeed (10/5Gbps), USB 2.0 High Speed (480Mbps) and USB 1.1 Low Speed (1.5Mbps).
4. No additional power supply required, built-in self-powered IC. Compatible with Windows 7, 8, 10, 11 and Mac OS 10.8.2 and above. Windows 10, 11, Mac OS and Linux systems do not require driver installation. Windows 7 systems require driver installation.
5. This interface can transmit USB 3.1/3.0 data and power, and can also connect USB-C video devices. The Type-C interface is a new design of USB 3.1. It adopts a reversible plug-in design and supports 5V/3A charging.

Parameters
Name: Desktop Type-c video expansion card USB3.2 10G+DP1.4 video output card
Input interface 1: Compatible slots: PCIe x4, PCIe x8, PCIe x16
Speed: 10GBPS
Input interface 2: Mini DisplayPort 4K
Output interface 1: Type-C female port, supports 10Gbps transmission rate
Output interface 2: Type-C female port, supports 10Gbps transmission rate and 4K 60Hz video output
Supported chassis: Supported by both large and small chassis
System support: Windows/Linux
Product size: 80*57 (PCB board size, excluding baffle)

Note:
Due to different monitor settings and lighting conditions, the actual color of the item may vary slightly from the pictures. Thanks for your understanding!
Please allow a 1-2 cm difference in measurements due to manual measuring.
