Y&H 2200VA 3200VA Hybrid Solar inverter 12V 24V DC 220V AC 1.8KW 3KW Off Grid Inverter 80A MPPT Solar Charger Pure Sine Wave

Y&H 2200VA 3200VA Hybrid Solar inverter 12V 24V DC 220V AC 1.8KW 3KW Off Grid Inverter 80A MPPT Solar Charger Pure Sine Wave

(4 customer reviews)

563.71$ – 1,008.00$

In Stock

Color

Input Voltage

No WiFi
with WIFI

Output Voltage

220-240V

Ships From

UNITED KINGDOM
brazil
GERMANY
United States

Clear

Description

High-concerned chemical: None
is_customized: Yes
Output Current: MPPT 80A
Model Number: SP
Size: 348mm*282mm*105mm
Output Type: SINGLE
Weight: 6.5KG
Brand Name: Y&H
Output Frequency: 50Hz/60Hz(Auto sensing)
Is Smart Device: Yes
Origin: Mainland China
Certification: CE
Type: DC/AC Inverters
Phase: Single Phase
Input Voltage: 12V/24V
Rated Load Power: 1800W/3000W
Max Panel Input Volt: 450V
AC Charging Current: 60 Amps
AC+PV Charging Current: 80Amps
PV Charging Current: 80amps
Battery Type 1: Lithium Batteries, Flooded Batteries, Gel Batteries, User Mode
Battery Type 2: Lead-acid Batteries, AGM Batteries
Load workout with Battery: No
Output Voltage: 220V
Output Voltage Waveform: Pure Sine Wave
Type 1: 1800W/3000W Solar Inverter
Type 2: Hybrid inverter
Type 3: Solar inverter

After EU customers order, the inverter will be shipped from our local EU warehouse within 24 hours.

The delivery time is about 3-7 days.

Please keep the default shipping from China when placing the order, so that when you make the final checkout The price will be automatically discounted to about 20% lower than the displayed price.

when you order before, please contact us first, thank you.

Y&H 2200VA 3200VA Hybrid Solar inverter 12V 24V DC 220V AC 1.8KW 3KW Off Grid Inverter 80A MPPT Solar Charger Pure Sine Wave

Do not turn on each input at the same time. It is recommended to work for 3 minutes. The inverter is working sufficiently and stably

Inverter startup sequence:

1: Battery 2: AC input or PV input 3: Load

The inverter exits the system sequence:

1: Load 2: AC input or PV input 3: Turn off the inverter Exit battery

Features：

Pure sine wave inverter

Programmable supply priority for PV, battery or Grid

High PV input voltage range(55~450VDC)

Reduce the cost of solar panels

Built-in Max 80A MPPT solar charge

Compatibe with lithium-ion battery

Support BMS communication with Lithium battery

Smart battery charge design to optimize battery life

Overload, high temperature,inverter output short circuit protection Intelligent fan speed adjustment

Built-in anti-dusk kit for harsh enviromen(optional)

WIFI&GPRS available for IOS and androidCold start function

Describe:

This is a multi-function inverter charger, combining functions of inverter, solar charger, and battery charger to offer uninterruptible power support with portable size.

Specification:

Models	SP-2200W-12V-M80A	SP-3200W-24V-M80A
RatedPower	2200VA/1800W	3200VA/3000W
INPUT
Voltage	230Vac
Selectable Voltage Range	(170Vac~280Vac)±2%；(90Vac-280Vac)±2%
Frequency Range	50Hz/60Hz (Autodetection)
OUTPUT
AC Voltage Regulation (Batt.Mode)	230VAC±5%
Surge power	4400VA	6400VA
Transfer Time	10ms(forpersonalcomputers)/20ms(forhomeappliances)
Waveform	PureSineWave
BATTERY&ACCHARGER
Battery Voltage	12VDC	24VDC
Floating Charge Voltage	13.5VDC	27VDC
Overcharge Protection	15.5VDC	31VDC
Maximum charge current	60A	60A
SOLARCHARGER
MAX PV Array Power	2000W	3000W
MPPT Range@Operating Voltage	55-450VDC
MaximumPVArrayOpenCircuit Voltage	450VDC
MaximumChargingCurrent	80A
Maximum Efficiency	98%
PHYSICAL
*Dimension.DWH(mm)*	348x282x105mm
Net Weight (kg)	5	5.5kg
Communi cati on Interface	RS232/RS485(Standard)/GPRS/WIFI(Optional)
OPERATINGENVIRONMENT
Humidity	5%to95%RelativeHumidity(Non-condensing)
OperatingTemperature	-10°Cto55°C
StorageTemperature	-15°Cto60°C

SP-2200VA/1800WSP-3200VA/3000WSP-2200VA/1800WSP-3200VA/3000W

w/LCD & LED DISPLAY:

LCD display designand 3 LED indicators for dynamic display of system data and operating status, Configurable battery charging current, AC/Solar Charger priority and Load Supply Priority via LCD setting. Support WIFI remote monitoring, users can monitor the status of the PV system from the mobile phone or from the website anytime anywhere. (Not included).MULTIPLE CHARGING MODES:

Off Grid Solar Inverter have 4 charging modes are optional, i.e. Only Solar, Mains Frist , Solar Frist and Mains & Solar hybrid charging;and 3 output modes are available, i.e. Solar Frist, Mains Frist and SBU Priority, uninterrupted power supply to meet different application requirements. And compatible to mains voltage or generator power, Auto restart while AC is recovering.Pure sine Wave Inverter：

built in 80A Mppt charge controller, is a new all-in-one hybrid solar inverter charger, fit for 12V Lead-Acid (Seal, AGM,Gel, Flooded) and Lithium batteryWIDE RANGE OF USES:

MPPT Inverter Charger Pure sine Wave 2200W for RV Camping Boat Home Emergency ect.. Can be accessed to a variety of household and office loads, including Oven, rice cooker, lamps, televisions, fans and other AC loads.

Bulit in 80amp mppt controller, which integrates solar energy storage &means charging energy storage and AC sine wave output.It can be widely used in DC to AC areas, such as solar AC power system, vehicle system, RV power supply, security monitoring system, emergency lighting system, field power system, household power system, etc.

Additional information

Color	SP-2200VA-12VBAT, SP-3200VA-24VBAT
High-concerned chemical	None
is_customized	Yes
Output Current	MPPT 80A
Model Number	SP
Size	348mm282mm105mm
Output Type	SINGLE
Weight	6.5KG
Brand Name	Y&H
Output Frequency	50Hz/60Hz(Auto sensing)
Is Smart Device	Yes
Origin	Mainland China
Certification	CE
Type	DC/AC Inverters
Phase	Single Phase
Input Voltage	12V/24V
Rated Load Power	1800W/3000W
Max Panel Input Volt	450V
AC Charging Current	60 Amps
AC+PV Charging Current	80Amps
PV Charging Current	80amps
Battery Type 1	Lithium Batteries, Flooded Batteries, Gel Batteries, User Mode
Battery Type 2	Lead-acid Batteries, AGM Batteries
Load workout with Battery	No
Output Voltage	220V
Output Voltage Waveform	Pure Sine Wave
Type 1	1800W/3000W Solar Inverter
Type 2	Hybrid inverter
Type 3	Solar inverter
Input Voltage	No WiFi, with WIFI
Output Voltage	220-240V
Ships From	UNITED KINGDOM, brazil, GERMANY, United States
