ZBT Dual SIM Card 5G Router 2*SIM Wifi6 3000Mbps Openwrt DDR4 1GB 4*LAN USB3.0 5G Modem MU-MIMO 4T4R Antenna Wifi Booster
Description
- High-concerned chemical: None
- 5G Wi-Fi Transmission Rate: 2167Mbps
- Wired Transfer Rate: 10/100/1000Mbps
- Wi-Fi Transmission Standard: 802.11ac
- 2.4G Wi-Fi Transmission Rate: 600mbps
- Wi-Fi Supported Frequency: 2.4G & 5G
- Supports WPS: Yes
- Supports WDS: Yes
- Number of USB Interfaces: 1 x USB 3.0
- WAN Ports: 1 x10/100/1000Mbps
- LAN Ports: 4
- Function: Firewall,QoS,VPN
- Application: Home
- Package: Yes
- Standards And Protocols: Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n,Wi-Fi 802.11ac
- Wireless transmission rate: 3000M
- Support Mesh: Support
- Frequency: 5 GHz
- Antenna Type: Fixed
- Recommended Uses: Home
- Wireless Communication Standard: 802.11.a
- Frequency Band Class: Dual-Band
- Model Name: Z8102AX-M2-T
- Max. LAN Data Rate: 1750Mbps
- With Modem Function: No
- Type: WireLess
- Brand Name: ZbT
- Origin: Mainland China
- Certification: CE,FCC
- Model: Z8102AX–T router
- Module type: two M.2 slot design
- Sim card slot: two SIM card
- Ram Flash: DDR4 1GB, 128MB SPINAND Flash
- Ethernet: 4*LAN 1*WAN USB3.0
- Function: WIFI 6, MESH
- 2.4GHz WIFI: 574Mbps speed
- 5GHz WIFI: 2400Mbps speed
- Wi-fi frequency: 2.4GHz 5GHz
- Wireless speed: 3000Mbps wifi MAX
- Lan port: 4*10/100/1000 Mbps Auto MDI/MDIX
- Wan port: 1*10/100/1000 Mbps Auto MDI/MDIX
- Network protocol: IEEE 802.11ax/n/g/b, IEEE 802.11ac/a
- Button: 1 Mesh Button, 1 Reset Button
- Wifi users: 256 user MAX
- Antenna: 4T4R MU-MIMO antenna
- Antenna type: 2*2.4ghz, 3*5.8ghz, 4 * 4g/5g
- Antennas: removable, SMA connector
- Weight: 1.25KG
- size: 320*210*180mm
- Product Feature 1: 5g sim Router
- Product Feature 2: 5g M.2 Router
- Product Feature 3: Dual sim Router
- Product Feature 4: 5g wifi Router
- Product Feature 5: Openwrt Router
- Product Feature 6: 5g NR Router
- Product Feature 7: 5ghz Router
- Product Feature 8: wifi6 Router
- Product Feature 9: 5g wifi6 Router
- Product Feature 10: 3000Mbps Router
- Product Feature 11: dual sim Router
- Product Feature 12: two sim Router
- Product Feature 13: sim card Router
- Product Feature 14: Router with dual sim
- Product Feature 15: 5g modem Router
- Product Feature 16: DDR4 RAM Router
- Product Feature 17: 5g Home Router
- Product Feature 18: 2 sim Router
- Product Feature 19: sim card 5g Router
- Product Feature 20: 5G Openwrt Router
USB3.0 4*1000Mbps LAN 1*WAN 8 Antennas 4T4R MU-MIMO, 2.4Ghz 5GHz Wifi for 256 user
【 If you want to use 2 SIM cards, you must purchase/install 2 identical modules. Similarly, one module can only use one SIM card 】
1. Relevant standards and specifications:
① Support IEEE802.11N/G/B/a/ac/ax, IEEE802.3/802.3u/802.ab network protocol, the max transmission rate could be 3000Mbps
② 5*10/100/1000 Mbps Auto MDI/MDIX
③ Independent WIFI6 MT7981B chip, supporting smooth connection of 256 devices
2. Main Features:
● Adopting MT7981B chip, ARM Cortext-A53 dual core CPU, with a main frequency of up to 1.3GHz
● Dual band 2.4ghz 5ghz concurrent wireless rate up to 3000mbps
● Support MU-MIMO, and WiFi modulation mode supports 1024-qam and OFDMA, Can connect 256 WiFi users
● Supporting IPv6 technology, with larger address space, improve the forwarding efficiency of WiFi 6 router
● Each WiFi channel is independently equipped with high-power FEM, which is combined with high gain antenna to achieve super WiFi coverage
● High speed 1GB DDR4 , paired with 128MB SPINAND Flash
● Supporting mesh one click technology, intelligent networking, plug and play
● Full 1000Mbps adaptive network interface of 1 WAN and 4 LAN, supporting automatic flip (auto MDI / mdix)
● Built-in two m.2 interface is used to connect 5g/4G module, and the module power supply is independently controlled through GPIO
3. Package List:
1 X Z8102AX–T Router
1 X Power adapter
1 X User Manual
Our company (factory) has a lot of products and inventory of other products. Welcome to learn about us.
Additional information
| High-concerned chemical | None |
|---|---|
| 5G Wi-Fi Transmission Rate | 2167Mbps |
| Wired Transfer Rate | 10/100/1000Mbps |
| Wi-Fi Transmission Standard | 802.11ac |
| 2.4G Wi-Fi Transmission Rate | 600mbps |
| Wi-Fi Supported Frequency | 2.4G & 5G |
| Supports WPS | Yes |
| Supports WDS | Yes |
| Number of USB Interfaces | 1 x USB 3.0 |
| WAN Ports | 1 x10/100/1000Mbps |
| LAN Ports | 4 |
| Function | WIFI 6, MESH |
| Application | Home |
| Package | Yes |
| Standards And Protocols | Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n,Wi-Fi 802.11ac |
| Wireless transmission rate | 3000M |
| Support Mesh | Support |
| Frequency | 5 GHz |
| Antenna type | 2*2.4ghz, 3*5.8ghz, 4 * 4g/5g |
| Recommended Uses | Home |
| Wireless Communication Standard | 802.11.a |
| Frequency Band Class | Dual-Band |
| Model Name | Z8102AX-M2-T |
| Max. LAN Data Rate | 1750Mbps |
| With Modem Function | No |
| Type | WireLess |
| Brand Name | ZbT |
| Origin | Mainland China |
| Certification | CE,FCC |
| Model | Z8102AX–T router |
| Module type | two M.2 slot design |
| Sim card slot | two SIM card |
| Ram Flash | DDR4 1GB, 128MB SPINAND Flash |
| Ethernet | 4*LAN 1*WAN USB3.0 |
| 2.4GHz WIFI | 574Mbps speed |
| 5GHz WIFI | 2400Mbps speed |
| Wi-fi frequency | 2.4GHz 5GHz |
| Wireless speed | 3000Mbps wifi MAX |
| Lan port | 4*10/100/1000 Mbps Auto MDI/MDIX |
| Wan port | 1*10/100/1000 Mbps Auto MDI/MDIX |
| Network protocol | IEEE 802.11ax/n/g/b, IEEE 802.11ac/a |
| Button | 1 Mesh Button, 1 Reset Button |
| Wifi users | 256 user MAX |
| Antenna | 4T4R MU-MIMO antenna |
| Antennas | removable, SMA connector |
| Weight | 1.25KG |
| size | 320*210*180mm |
| Product Feature 1 | 5g sim Router |
| Product Feature 2 | 5g M.2 Router |
| Product Feature 3 | Dual sim Router |
| Product Feature 4 | 5g wifi Router |
| Product Feature 5 | Openwrt Router |
| Product Feature 6 | 5g NR Router |
| Product Feature 7 | 5ghz Router |
| Product Feature 8 | wifi6 Router |
| Product Feature 9 | 5g wifi6 Router |
| Product Feature 10 | 3000Mbps Router |
| Product Feature 11 | dual sim Router |
| Product Feature 12 | two sim Router |
| Product Feature 13 | sim card Router |
| Product Feature 14 | Router with dual sim |
| Product Feature 15 | 5g modem Router |
| Product Feature 16 | DDR4 RAM Router |
| Product Feature 17 | 5g Home Router |
| Product Feature 18 | 2 sim Router |
| Product Feature 19 | sim card 5g Router |
| Product Feature 20 | 5G Openwrt Router |
| Bundle | 5G RM500U, 5G RM520N-GL, NO 5G Modem NO WIFI, Two 5G RM500U, Two SIM RM520N-GL |
| Color | Z8102AX-M2-T |
