Description
- Whether or Not 50Vac or 75Vdc or Higher Power Supply: No
- High-concerned chemical: None
- Zoom type: None
- Zoom: None
- Lens Quantity: Dual Lens
- AI Functions: Human Detection
- Color Night Vision: Yes
- Operating Temperature: -10°-60°
- IP Rating: IP66
- Scene: Indoor and outdoor
- Megapixels: 4MP
- TF Card: None
- Power Supply: With Poe
- Internal Storage: None
- Installation: Ceiling
- Color: WHITE
- is_customized: Yes
- Audio Output: Two Way Audio
- Minimum Illumination(Lux): 0Lux IR on
- Viewing Angle : 100°
- Video Compression Format: H.264,H.265,MJPEG
- IR Distance(m): 20-30m
- Power Supply(V): 12 VDC POE
- Power Consumption(W): 5W
- Supported Mobile Systems: Android,iOS
- Sensor: CMOS
- Model Number: PG2046IRCS-P/PG2346IRCS-P/PG2086IRCS-P/PG2386IRCS-P
- Supported Operating Systems: Windows XP,Windows 7,Windows 8,Windows 2008,Windows 10,Windows 2003,Windows 2000,Windows Vista,Windows 98
- Lens (mm): 4mm
- Connectivity: IP/Network Wired
- High Definition: 4.0 Megapixels
- Style: Bullet Camera
- Brand Name: Ziksecu
- Origin: Mainland China
- Certification: CE
- Smart home platform: Other
- Power Source: With Poe
- Feature 1: security protection mini camera
- Feature 2: smart home camera video surveillance
- Feature 3: webcam camera de seguranca
- Feature 4: cctv camera telecamera sorveglianza
- Feature 5: camara de seguridad outdoor
- Feature 6: night vision home appliance
Hikvision Compatible 4MP 8MP Panoramic Colorvu IP Camera Built in Mic Speaker Human Detection CCTV Surveillance Network Cameras
>APP：VIDEOLINK（IOS,Android）, support download by QR code（If the camera needs to be added to the NVR, use the NVR APP management）
>Search Tool：SADP /AjDevTools（modify the default ip address and password）
>Retset Tool：Videolink/ Internet Explorer
>Default IP：192.168.1.110
>Username：admin
>Password：123456
>>>Notice ： This camera isNOT HIKVISION ORIGINAL, is HikvisionCompatible, itcan plug & play with Hikvision NVR, support most of the other brands NVR that support On-Vif protocol，and the camera can be worked with most of security monitor software, likeBlue Iris, iSpy, VLC, and so on
4/8MP Dual illumination Panoramic Network Camera
>High quality imaging with 4/8 MP resolution
>4MP (3840*1080 170°&40°)；8MP(4096*1944 160°&70°)
>One image that presents all the scenes covered by the camera
>24/7 colorful imaging
>Efficient H.265+ compression technology
>Clear imaging against strong back light due to 120 dB WDR technology
>Motion Detection
>Smart Dual Light, with 3 light mode
>Water and dust resistant
1.Camera
Image Sensor : 4MP:1/2.9" GC2063 CMOS; 8MP:1/2.7" GC5623 CMOS
Min. Illumination : Color: 0.05lux @(F1.6), 0 lux with IR light
Shutter Speed : 1/10 s to 1/10,000 s
Slow Shutter : Yes
Day & Night : IR CUT Filter
Digital Noise Reduction : 3D DNR 2D DNR
WDR : 120dB
Angle Adjustment : Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°
2.Lens
Focal Length : Fixed focal lens,dual lens, 4MP(4mm*2),8MP(2.8mm*2)
Aperture : F1.6
Focus : Fixed
Focus Length & FOV : 4MP(horizontal FOV: 170°, vertical FOV: 40°); 8MP(horizontal FOV: 160°, vertical FOV: 70°)
Lens Mount : M12
3.Illuminator :
White Light & IR Range : Up to 30 m
Smart Supplement Light : Yes
4.Compression Standard :
Main stream: H.265+/H.265/H.264
Video Compression : Sub-stream: H.265+/H.265/H.264
H.264 Type : High Profile/Main Profile/Base Profile
H.265 Type : High Profile/Main Profile/Base Profile
H.265+ : High Profile/Main Profile/Base Profile
5.Smart Feature-set :
Smart Event : 4MP(Human detection),Vehice detection; 8MP(Human detection,Vehice detection)
Basic Event : Motion detection
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email
Linkage Method : Trigger notification: HTTP, Email
6.Image :
Max. Resolution : 4MP(3840 × 1080); 8MP(4096 × 1944)
Main Stream : 4MP(3840 × 1080 20fps); 8MP(4096 × 1944 20fps)
Sub-Stream : 4MP(1280 x 360 20fps); 8MP(20 fps 1280 x 360 ；20 fps 768 x 360)
Image Enhancement : WDR/HDR/3D DNR/2D DNR/HLC/BLC
Image Setting : Rotate mode, saturation, brightness, contrast, sharpness, and white balance adjustable by client software or web browser
SVC : H.264 and H.265 encoding support
Day/Night Switch : Day/Night/Auto/Schedule
7.Network
Network Storage : Support local storage and NAS (NFS, SMB/CIFS)
Protocols : HTTP, RTSP, DHCP, FTP, NTP,ONVIF,P2P,SMTP,RTMP
Client : AJ_Client,AVideolink,LMS
8.Interface :
Communication Interface : 1 RJ45 10M/100M self-adaptive Ethernet port
Built-in Microphone : Yes
Built-in Speaker : Power: 3W.MAX. Sound pressure lever:10cm: 100dB.
Reset Key : Yes
On-Board Storage : Built-in memory card slot, support microSD card,up to 512GB
9.General
Operating Conditions : -30 °C to +85 °C, humidity 95% or less (non-condensing)
Web Client Language : 14 languages: English,Russian,German,Italian,Turkish, Korean,Japanese,Traditional Chinese,Simple Chinese,Ukrainian,Portuguese,Croatian,Polish,Farsi
Power Consumption and Current : DC 12V, 1 A, max. 10 W Φ 5.5X2.1 mm coaxial plug power
PoE (802.3af, 36 V to 57 V), 0.35 A to 0.22 A, max. 12.5W
*Bullet :
Protection Level : IP67-Each Camera has been tested waterproof
Material : Front cover:metal,body:metal,bracket:metal
Camera: 236.1 × 110 x 74mm (9.29" × 4.33 x 2.91")
Dimensions : Package: 325 × 125 × 120 mm (12.8" × 4.92" × 4.7" )
Weight : Apporx.650g(1.43 lb)
With Package Weight : Apporx.800g(1.76 lb)
*Turret :
Protection Level : IP66-Each Camera has been tested waterproof
Material : Front cover:metal,body:plastic,bracket:plastic
Dimensions : Camera: 137.5 × 100mm (5.41" × 3.94")
Package: 173 × 173 × 120 mm (6.81" × 6.81" × 4.7" )
Weight : Apporx.460g(1.01 lb)
With Package Weight : Apporx.600g(1.32 lb)
SMART H.264/H.265
