M5Stack Tiny NanoH2 IoT Development Board Kit Support Thread Matter Interoperability Protocols Based on Thread for Smart home

3256810516673491

~~62.07$~~ 54.06$

In Stock

(0 customer reviews)

Color

Clear

Description

High-concerned chemical: None
Model: NanoH2
Type: MCU/Single Chip Microcomputer
Origin: Mainland China
Brand Name: M5Stack

M5Stack Tiny NanoH2 IoT Development Board

Product Features

Supports Zigbee and Thread, Matter wireless protocols
Built-in LED, IR infrared transmitter, and RGB
Equipped with a Grove port, supporting multiple peripheral expansions
USB Type-C interface for power supply and programming
Compact size
Development Platform
Arduino
ESP-IDF

Applications

Smart home
Industrial control
Consumer electronics
Low-power wireless communication nodes

Package Includes

1 x NanoH2

Specification

Product details

Product Description

NanoH2 is an ultra-compact IoT development board in the M5Stack development kit series. It is powered by the ESP32-H2FH4S as the SoC and features hardware security mechanisms such as secure boot and Flash encryption. The device integrates IEEE 802.15.4 wireless communication and supports Zigbee, Thread, and Matter interoperability protocols based on Thread. The hardware integrates an LED, IR infrared transmitter, RGB, Grove interface, USB Type-C, and a user button. The Grove interface enables flexible expansion with various M5 devices, providing developers with rich hardware expansion capabilities. It is suitable for functional extension needs in lightweight IoT scenarios and can be applied in smart home, industrial control, low-power wireless communication nodes, and the development of various low-power IoT terminals based on IEEE 802.15.2.

Download Mode

To flash firmware, you need to enter download mode: press and hold the button GPIO9, then connect the USB cable to enter download mode.

Additional information

Color	NanoH2
High-concerned chemical	None
Model	NanoH2
Type	MCU/Single Chip Microcomputer
Origin	Mainland China
Brand Name	M5Stack
