M5Stack Tiny NanoH2 IoT Development Board Kit Support Thread Matter Interoperability Protocols Based on Thread for Smart home
In Stock
Loading...
Description
- High-concerned chemical: None
- Model: NanoH2
- Type: MCU/Single Chip Microcomputer
- Origin: Mainland China
- Brand Name: M5Stack
Â
M5Stack Tiny NanoH2 IoT Development Board
Â
 Product FeaturesÂ
-
Supports Zigbee and Thread, Matter wireless protocols
-
Built-in LED, IR infrared transmitter, and RGB
-
Equipped with a Grove port, supporting multiple peripheral expansions
-
USB Type-C interface for power supply and programming
-
Compact size
-
Development Platform
-
Arduino
-
ESP-IDF
 ApplicationsÂ
-
Smart home
-
Industrial control
-
Consumer electronics
-
Low-power wireless communication nodes
 Package IncludesÂ
Â
1 x NanoH2
 SpecificationÂ
Â
Â
 Product detailsÂ
Â
Â
 Product DescriptionÂ
Â
NanoH2 is an ultra-compact IoT development board in the M5Stack development kit series. It is powered by the ESP32-H2FH4S as the SoC and features hardware security mechanisms such as secure boot and Flash encryption. The device integrates IEEE 802.15.4 wireless communication and supports Zigbee, Thread, and Matter interoperability protocols based on Thread. The hardware integrates an LED, IR infrared transmitter, RGB, Grove interface, USB Type-C, and a user button. The Grove interface enables flexible expansion with various M5 devices, providing developers with rich hardware expansion capabilities. It is suitable for functional extension needs in lightweight IoT scenarios and can be applied in smart home, industrial control, low-power wireless communication nodes, and the development of various low-power IoT terminals based on IEEE 802.15.2.
Â
Download Mode
To flash firmware, you need to enter download mode: press and hold the button GPIO9, then connect the USB cable to enter download mode.
Additional information
| Color | NanoH2 |
|---|---|
| High-concerned chemical | None |
| Model | NanoH2 |
| Type | MCU/Single Chip Microcomputer |
| Origin | Mainland China |
| Brand Name | M5Stack |
